Swarm-Contrastive Decomposition 🧠

A Python package for decomposition of neurophysiological time series signals using a Particle Swarm Optimised Independence Estimator for Blind Source Separation.

Table of Contents 📚

• Installation
• Quick Start
• Usage
• Configuration
• Test Data
• Contributing
• License
• Citation
• Contact

Installation 🛠️

From PyPI (Recommended)

pip install swarm-contrastive-decomposition

From GitHub (Latest Development Version)

pip install git+https://github.com/AgneGris/swarm-contrastive-decomposition.git

From Source

git clone https://github.com/AgneGris/swarm-contrastive-decomposition
cd swarm-contrastive-decomposition
pip install -e .

Verify Installation

python -c "import scd; print(f'SCD version: {scd.__version__}')"

Quick Start 🚀

import scd

# Train with default configuration
dictionary, timestamps = scd.train("path/to/your/data.mat")

# Save results
scd.save_results("data/output/emg.pkl", dictionary)

Usage

Basic Usage

import scd

# Use a predefined configuration
dictionary, timestamps = scd.train(
    "path/to/your/data.mat",
    config_name="surface"  # or "default", "intramuscular"
)

scd.save_results("output.pkl", dictionary)

With Configuration Overrides

import scd

# Override specific parameters
dictionary, timestamps = scd.train(
    "path/to/your/data.mat",
    config_name="surface",
    max_iterations=100,  # override for quick testing
    output_final_source_plot=True
)

Step-by-Step Control

import scd

# Load configuration
config = scd.load_config("surface")

# Load data
neural_data = scd.load_data("path/to/your/data.mat", device=config.device)

# Preprocess
neural_data = scd.preprocess_data(neural_data, config)

# Train model
dictionary, timestamps = scd.train_model(neural_data, config)

# Save results
scd.save_results("output.pkl", dictionary)

Supported Data Formats

• .mat — MATLAB files, including HDF5-based v7.3 files (specify the variable name with key parameter)
• .npy — NumPy arrays

# For .mat files with custom variable name
dictionary, timestamps = scd.train("data.mat", key="emg_data")

# For .npy files
dictionary, timestamps = scd.train("data.npy")

Data should have shape (time, channels) or (channels, time) — the loader will automatically transpose if needed.

Configuration ⚙️

Configurations are defined in scd/configs.json. Available presets:

Config Name	Use Case	Sampling Rate	Description
default	General purpose	10240 Hz	Balanced settings for most EMG data
surface	Surface EMG	10240 Hz	Optimized for surface recordings
intramuscular	Intramuscular EMG	10240 Hz	Higher iterations for fine-wire recordings

Configuration Parameters

Parameter	Description	Default
device	"cuda" for GPU or "cpu"; automatically selected when omitted	CUDA when available, otherwise CPU
acceptance_silhouette	Quality threshold for source acceptance	0.85
extension_factor	Leave unset to derive 1000 / kept channels automatically. Set it to override. Never capped — see Choosing the Extension Factor	derived
bad_channels	Channel indices to reject. Replaced with noise at the estimated baseline amplitude of the good channels before decomposition, and excluded from the kept-channel count used to derive extension_factor	null
low_pass_cutoff	Low-pass filter cutoff frequency (Hz)	4400
high_pass_cutoff	High-pass filter cutoff frequency (Hz)	10
sampling_frequency	Sampling frequency of your signal (Hz)	10240
start_time	Start time for signal trimming (s). Use 0 for beginning	0
end_time	End time for signal trimming (s). Use -1 for entire signal	-1
max_iterations	Maximum decomposition iterations	200
peel_off_window_size_ms	Window size for spike-triggered average (ms). peel_off_window_size in samples is derived automatically as ms × fs / 1000	20
reset_peak_separation_ms	Minimum distance between two detected peaks in the source signal (ms), converted to samples as ms × fs / 1000	4.0
edge_mask_size_ms	Masked region at each end of the signal during optimisation (ms), converted to samples as ms × fs / 1000. Set edge_mask_size instead to pin a raw sample count	19.5
output_final_source_plot	Generate plot of final sources	false
use_coeff_var_fitness	Use coefficient of variation fitness. true for EMG, false for intracortical	true
remove_bad_fr	Filter sources with firing rates < 2 Hz or > 100 Hz	true
adapt_clamp	Adaptively clamp each source using its personal-best spike statistics; falls back to hard ±30 σ when no spike history exists. Set to false to always use the fixed ±30 σ hard clamp	true

Custom Configuration

Add your own configuration to scd/configs.json:

{
    "my_experiment": {
        "device": "cuda",
        "acceptance_silhouette": 0.80,
        "extension_factor": 30,
        "sampling_frequency": 2048,
        ...
    }
}

Then use it:

dictionary, timestamps = scd.train("data.mat", config_name="my_experiment")

Choosing the Extension Factor

K is chosen so that the extended observation matrix has on the order of 1000 rows:

K  ≈  1000 / M          M = kept channels = total channels − bad_channels

This is the default. If extension_factor is absent from your config, SCD derives it from the channel count of the data you pass in and logs the value it used:

INFO - extension_factor not set; using 16 (1000 / 63 kept channels)

Set extension_factor explicitly in your config to override it with any value you like — the derived default applies only when it is unset. All three built-in presets set it explicitly.

To compute the same number yourself:

from scd import recommended_extension_factor

K = recommended_extension_factor(num_channels=64, bad_channels=[56])   # 16

Whatever you set is used as-is: SCD never rejects or adjusts an extension factor. Note that larger K costs time and memory, as the covariance and whitening stages scale roughly with (K · M)² and (K · M)³ respectively, and that whitening runs on CPU.

Changed in 0.2.0

This release contains breaking changes. Configs written for 0.1.x may need editing — Config rejects unknown keys, so a removed parameter left in a config file raises TypeError on load.

No extension factor is rejected any more. Versions 0.1.7 and 0.1.8 validated extension_factor against a temporal-separation bound K ≤ T − L and raised a ValueError when it was exceeded. That bound is uninformative: SCD's assumed MUAP duration (peel_off_window_size_ms, 20 ms) equals the minimum ISI at max_firing_rate_hz = 50, so it evaluates to zero at every sampling rate. In practice it blocked valid configurations, particularly at lower sampling rates such as 2048 Hz, where the standard 1000 / M choice exceeds it.

Removed	Reason
compute_extension_factor_bounds()	Both bounds it returned are unreachable in practice
max_firing_rate_hz	Only ever fed the removed checks
final_peak_separation	Referenced nowhere

Changed defaults:

• extension_factor was a fixed 100, which silently produced badly over-extended runs for any config that omitted the key. It is now unset by default and derived as 1000 / kept channels.
• edge_mask_size is now specified in ms as edge_mask_size_ms and scaled by the sampling rate; it was a raw sample count tuned for 10 240 Hz. Set edge_mask_size to pin a sample count instead.
• Rejected channels are replaced with baseline noise rather than zeroed. Zeroing left exactly-zero rows in the extended matrix, making the covariance rank-deficient and letting whitening amplify those directions. Amplitude comes from estimate_baseline_noise, a MAD-based estimate of the noise floor between discharges.

Runs using bad_channels will give different results than 0.1.x. Note also that scd-edition scales its channel fill by the pooled standard deviation of the good channels, which includes MUAP activity; pass noise_std explicitly to replace_bad_channels_with_noise to reproduce its output.

Test Data 🧪

The source repository includes test data to verify a development installation:

• File: data/input/emg.mat
• Type: Surface EMG
• Sampling rate: 10240 Hz
• Configuration: Use "surface" config

import scd

# Run with test data
dictionary, timestamps = scd.train(
    "data/input/emg.mat",
    config_name="surface"
)

print(f"Found {len(dictionary)} motor units")

Contributing 🤝

We welcome contributions! Here's how you can contribute:

1. Fork the repository
2. Create a feature branch (git checkout -b feature/newfeature)
3. Commit your changes (git commit -m 'Add some newfeature')
4. Push to the branch (git push origin feature/newfeature)
5. Open a pull request

License 📜

This project is licensed under the BSD 3-Clause License.

Citation

If you use this code in your research, please cite our paper:

@article{grison2024particle,
  author={Grison, Agnese and Clarke, Alexander Kenneth and Muceli, Silvia and Ibáñez, Jaime and Kundu, Aritra and Farina, Dario},
  journal={IEEE Transactions on Biomedical Engineering},
  title={A Particle Swarm Optimised Independence Estimator for Blind Source Separation of Neurophysiological Time Series},
  year={2025},
  volume={72},
  number={1},
  pages={227--237},
  doi={10.1109/TBME.2024.3446806},
  keywords={Recording; Time series analysis; Sorting; Vectors; Measurement; Electrodes; Probes; Independent component analysis; particle swarm optimisation; blind source separation; intramuscular electromyography; intracortical recording}
}

@article{grison2025unlocking,
  title={Unlocking the full potential of high-density surface EMG: novel non-invasive high-yield motor unit decomposition},
  author={Grison, Agnese and Mendez Guerra, Irene and Clarke, Alexander Kenneth and Muceli, Silvia and Ib{\'a}{\~n}ez, Jaime and Farina, Dario},
  journal={The Journal of Physiology},
  volume={603},
  number={8},
  pages={2281--2300},
  year={2025},
  publisher={Wiley Online Library}
}
