AWS Container Services Setup Guide: ECR, ECS, and EKS

Comprehensive guide for setting up Amazon Elastic Container Registry (ECR), Amazon Elastic Container Service (ECS), and Amazon Elastic Kubernetes Service (EKS) with CLI automation and Infrastructure as Code.

Prerequisites
Amazon ECR Setup
Amazon ECS Setup
Amazon EKS Setup
Terraform IaC Examples
Security Best Practices
Monitoring and Logging

1. Prerequisites

1.1. Required Tools

# Install AWS CLI v2
curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"
unzip awscliv2.zip
sudo ./aws/install

# Verify installation
aws --version

# Install Docker
sudo apt-get update
sudo apt-get install docker.io -y
sudo usermod -aG docker $USER

# Install kubectl
curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
chmod +x kubectl
sudo mv kubectl /usr/local/bin/

# Install eksctl
curl --silent --location "https://github.com/weaveworks/eksctl/releases/latest/download/eksctl_$(uname -s)_amd64.tar.gz" | tar xz -C /tmp
sudo mv /tmp/eksctl /usr/local/bin

1.2. AWS Configuration

# Configure AWS CLI
aws configure

# Verify configuration
aws sts get-caller-identity

2. Amazon ECR Setup

2.1. Create ECR Repository (CLI)

# Create repository
aws ecr create-repository \
    --repository-name my-app-repo \
    --region us-west-2 \
    --image-scanning-configuration scanOnPush=true \
    --encryption-configuration encryptionType=AES256

# Set lifecycle policy to clean up old images
aws ecr put-lifecycle-policy \
    --repository-name my-app-repo \
    --region us-west-2 \
    --lifecycle-policy-text '{
        "rules": [
            {
                "rulePriority": 1,
                "description": "Keep last 10 images",
                "selection": {
                    "tagStatus": "tagged",
                    "tagPrefixList": ["v"],
                    "countType": "imageCountMoreThan",
                    "countNumber": 10
                },
                "action": {
                    "type": "expire"
                }
            },
            {
                "rulePriority": 2,
                "description": "Delete untagged images older than 7 days",
                "selection": {
                    "tagStatus": "untagged",
                    "countType": "sinceImagePushed",
                    "countUnit": "days",
                    "countNumber": 7
                },
                "action": {
                    "type": "expire"
                }
            }
        ]
    }'

2.2. Build and Push Docker Image

# Get ECR login password and authenticate Docker
aws ecr get-login-password --region us-west-2 | \
    docker login --username AWS --password-stdin \
    $(aws sts get-caller-identity --query Account --output text).dkr.ecr.us-west-2.amazonaws.com

# Build Docker image
docker build -t my-app:latest .

# Tag image for ECR
docker tag my-app:latest \
    $(aws sts get-caller-identity --query Account --output text).dkr.ecr.us-west-2.amazonaws.com/my-app-repo:latest

# Tag with version
docker tag my-app:latest \
    $(aws sts get-caller-identity --query Account --output text).dkr.ecr.us-west-2.amazonaws.com/my-app-repo:v1.0.0

# Push images to ECR
docker push $(aws sts get-caller-identity --query Account --output text).dkr.ecr.us-west-2.amazonaws.com/my-app-repo:latest
docker push $(aws sts get-caller-identity --query Account --output text).dkr.ecr.us-west-2.amazonaws.com/my-app-repo:v1.0.0

2.3. ECR IAM Policy

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "ECRReadWrite",
            "Effect": "Allow",
            "Action": [
                "ecr:GetDownloadUrlForLayer",
                "ecr:BatchGetImage",
                "ecr:BatchCheckLayerAvailability",
                "ecr:PutImage",
                "ecr:InitiateLayerUpload",
                "ecr:UploadLayerPart",
                "ecr:CompleteLayerUpload",
                "ecr:DescribeRepositories",
                "ecr:GetRepositoryPolicy",
                "ecr:ListImages",
                "ecr:DescribeImages",
                "ecr:BatchGetImage"
            ],
            "Resource": "arn:aws:ecr:us-west-2:ACCOUNT_ID:repository/my-app-repo"
        },
        {
            "Sid": "ECRGetAuthorizationToken",
            "Effect": "Allow",
            "Action": [
                "ecr:GetAuthorizationToken"
            ],
            "Resource": "*"
        }
    ]
}

3. Amazon ECS Setup

3.1. Create ECS Cluster (CLI)

# Create ECS cluster
aws ecs create-cluster \
    --cluster-name my-ecs-cluster \
    --region us-west-2

# Create CloudWatch log group
aws logs create-log-group \
    --log-group-name /ecs/my-app \
    --region us-west-2

3.2. Create ECS Task Definition

# Create task definition
aws ecs register-task-definition \
    --family my-app-task \
    --network-mode awsvpc \
    --requires-compatibilities FARGATE \
    --cpu "256" \
    --memory "512" \
    --execution-role-arn ecsTaskExecutionRole \
    --region us-west-2 \
    --container-definitions '[
        {
            "name": "my-app",
            "image": "ACCOUNT_ID.dkr.ecr.us-west-2.amazonaws.com/my-app-repo:latest",
            "cpu": 256,
            "memory": 512,
            "essential": true,
            "portMappings": [
                {
                    "containerPort": 80,
                    "protocol": "tcp"
                }
            ],
            "logConfiguration": {
                "logDriver": "awslogs",
                "options": {
                    "awslogs-group": "/ecs/my-app",
                    "awslogs-region": "us-west-2",
                    "awslogs-stream-prefix": "ecs"
                }
            },
            "environment": [
                {
                    "name": "ENVIRONMENT",
                    "value": "production"
                }
            ]
        }
    ]'

3.3. Create ECS Service

# Create security group for ECS
SG_ID=$(aws ec2 create-security-group \
    --group-name ecs-sg \
    --description "Security group for ECS" \
    --vpc-id vpc-xxxxxxxx \
    --region us-west-2 \
    --query 'GroupId' \
    --output text)

# Allow inbound traffic
aws ec2 authorize-security-group-ingress \
    --group-id $SG_ID \
    --protocol tcp \
    --port 80 \
    --cidr 0.0.0.0/0 \
    --region us-west-2

# Create ECS service
aws ecs create-service \
    --cluster my-ecs-cluster \
    --service-name my-app-service \
    --task-definition my-app-task \
    --desired-count 2 \
    --launch-type FARGATE \
    --network-configuration "awsvpcConfiguration={subnets=[subnet-xxxxxxxx,subnet-yyyyyyyy],securityGroups=[$SG_ID],assignPublicIp=ENABLED}" \
    --region us-west-2 \
    --deployment-configuration "maximumPercent=200,minimumHealthyPercent=100"

3.4. Create Application Load Balancer

# Create target group
TARGET_ARN=$(aws elbv2 create-target-group \
    --name my-app-tg \
    --protocol HTTP \
    --port 80 \
    --target-type ip \
    --vpc-id vpc-xxxxxxxx \
    --region us-west-2 \
    --query 'TargetGroups[0].TargetGroupArn' \
    --output text)

# Create load balancer
LB_ARN=$(aws elbv2 create-load-balancer \
    --name my-app-alb \
    --subnets subnet-xxxxxxxx subnet-yyyyyyyy \
    --security-groups $SG_ID \
    --region us-west-2 \
    --query 'LoadBalancers[0].LoadBalancerArn' \
    --output text)

# Create listener
aws elbv2 create-listener \
    --load-balancer-arn $LB_ARN \
    --protocol HTTP \
    --port 80 \
    --default-actions Type=forward,TargetGroupArn=$TARGET_ARN \
    --region us-west-2

4. Amazon EKS Setup

4.1. Create EKS Cluster (eksctl)

# eks-cluster-config.yaml
apiVersion: eksctl.io/v1alpha5
kind: ClusterConfig

metadata:
  name: my-eks-cluster
  region: us-west-2
  version: "1.29"

managedNodeGroups:
  - name: managed-nodes
    instanceType: t3.medium
    minSize: 2
    maxSize: 5
    desiredCapacity: 3
    volumeSize: 80
    ssh:
      allow: true
      publicKeyName: your-key-name
    labels:
      role: worker
    tags:
      Environment: production
    iam:
      withAddonPolicies:
        autoScaler: true
        albIngress: true
        cloudWatch: true

vpc:
  cidr: "10.0.0.0/16"
  nat:
    gateway: Single
  clusterEndpoints:
    publicAccess: true
    privateAccess: true

# Create cluster
eksctl create cluster -f eks-cluster-config.yaml

# Update kubeconfig
aws eks update-kubeconfig --name my-eks-cluster --region us-west-2

# Verify connection
kubectl get nodes

4.2. Create Kubernetes Deployment for ECR Image

# deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  namespace: default
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-app
        image: ACCOUNT_ID.dkr.ecr.us-west-2.amazonaws.com/my-app-repo:latest
        ports:
        - containerPort: 80
        resources:
          requests:
            cpu: 250m
            memory: 256Mi
          limits:
            cpu: 500m
            memory: 512Mi
        livenessProbe:
          httpGet:
            path: /health
            port: 80
          initialDelaySeconds: 30
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /ready
            port: 80
          initialDelaySeconds: 5
          periodSeconds: 5
---
apiVersion: v1
kind: Service
metadata:
  name: my-app-service
  namespace: default
spec:
  type: LoadBalancer
  selector:
    app: my-app
  ports:
  - port: 80
    targetPort: 80

# Deploy to EKS
kubectl apply -f deployment.yaml

# Verify deployment
kubectl get pods -l app=my-app
kubectl get services

4.3. Create Image Pull Secret

# Create secret for ECR authentication
kubectl create secret docker-registry ecr-secret \
    --docker-server=ACCOUNT_ID.dkr.ecr.us-west-2.amazonaws.com \
    --docker-username=AWS \
    --docker-password=$(aws ecr get-login-password --region us-west-2) \
    --docker-email=none

# Patch service account to use the secret
kubectl patch serviceaccount default \
    -p '{"imagePullSecrets": [{"name": "ecr-secret"}]}'

5. Terraform IaC Examples

5.1. ECR Terraform Module

# ecr.tf
resource "aws_ecr_repository" "my_app" {
  name                 = "my-app-repo"
  image_tag_mutability = "MUTABLE"

  image_scanning_configuration {
    scan_on_push = true
  }

  encryption_configuration {
    encryption_type = "AES256"
  }
}

resource "aws_ecr_lifecycle_policy" "my_app" {
  repository = aws_ecr_repository.my_app.name

  policy = jsonencode({
    rules = [
      {
        rulePriority = 1
        description  = "Keep last 10 images"
        selection = {
          tagStatus     = "tagged"
          tagPrefixList = ["v"]
          countType     = "imageCountMoreThan"
          countNumber   = 10
        }
        action = {
          type = "expire"
        }
      }
    ]
  })
}

5.2. EKS Terraform Module

# eks.tf
module "eks" {
  source  = "terraform-aws-modules/eks/aws"
  version = "~> 19.0"

  cluster_name    = "my-eks-cluster"
  cluster_version = "1.29"

  vpc_id     = module.vpc.vpc_id
  subnet_ids = module.vpc.private_subnets

  cluster_endpoint_public_access  = true
  cluster_endpoint_private_access = true

  eks_managed_node_groups = {
    main = {
      name           = "managed-nodes"
      instance_types = ["t3.medium"]
      min_size       = 2
      max_size       = 5
      desired_size   = 3

      labels = {
        role = "worker"
      }

      tags = {
        Environment = "production"
      }
    }
  }

  cluster_addons = {
    coredns = {
      most_recent = true
    }
    kube-proxy = {
      most_recent = true
    }
    vpc-cni = {
      most_recent = true
    }
  }
}

6. Security Best Practices

6.1. IAM Roles and Policies

# Create IAM role for ECS task execution
aws iam create-role \
    --role-name ecsTaskExecutionRole \
    --assume-role-policy-document file://trust-policy.json

# Attach managed policy
aws iam attach-role-policy \
    --role-name ecsTaskExecutionRole \
    --policy-arn arn:aws:iam::aws:policy/service-role/AmazonECSTaskExecutionRolePolicy

6.2. Security Groups

# Restrict security group to specific CIDR
aws ec2 authorize-security-group-ingress \
    --group-id $SG_ID \
    --protocol tcp \
    --port 80 \
    --cidr 10.0.0.0/16 \
    --region us-west-2

6.3. Secrets Management

# Store sensitive data in AWS Secrets Manager
aws secretsmanager create-secret \
    --name my-app/database \
    --secret-string '{"username":"admin","password":"securepassword"}' \
    --region us-west-2

# Retrieve secret in application
aws secretsmanager get-secret-value \
    --secret-id my-app/database \
    --region us-west-2

7. Monitoring and Logging

7.1. CloudWatch Logs

# Enable CloudWatch logging for ECS
aws ecs put-cluster-configuration \
    --cluster my-ecs-cluster \
    --execute-configuration '{"executeCommandConfiguration":{"logging":"OVERRIDE","logConfiguration":{"cloudWatchLogGroupName":"/ecs/my-app"}}}' \
    --region us-west-2

7.2. CloudWatch Metrics

# Create CloudWatch dashboard
aws cloudwatch put-dashboard \
    --dashboard-name my-app-dashboard \
    --dashboard-body file://dashboard.json \
    --region us-west-2

7.3. X-Ray Tracing

# Enable AWS X-Ray for ECS
aws ecs put-account-setting \
    --name accountSettingName:containerInsights \
    --value enabled \
    --region us-west-2

8. CI/CD Integration

8.1. GitHub Actions Example

# .github/workflows/deploy.yml
name: Deploy to AWS

on:
  push:
    branches: [ main ]

jobs:
  build-and-deploy:
    runs-on: ubuntu-latest

    steps:
    - uses: actions/checkout@v3

    - name: Configure AWS credentials
      uses: aws-actions/configure-aws-credentials@v2
      with:
        aws-access-key-id: ${{ secrets.AWS_ACCESS_KEY_ID }}
        aws-secret-access-key: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
        aws-region: us-west-2

    - name: Login to Amazon ECR
      id: login-ecr
      uses: aws-actions/amazon-ecr-login@v1

    - name: Build and push Docker image
      env:
        ECR_REGISTRY: ${{ steps.login-ecr.outputs.registry }}
        ECR_REPOSITORY: my-app-repo
        IMAGE_TAG: ${{ github.sha }}
      run: |
        docker build -t $ECR_REGISTRY/$ECR_REPOSITORY:$IMAGE_TAG .
        docker push $ECR_REGISTRY/$ECR_REPOSITORY:$IMAGE_TAG

    - name: Deploy to EKS
      run: |
        aws eks update-kubeconfig --name my-eks-cluster --region us-west-2
        kubectl set image deployment/my-app my-app=$ECR_REGISTRY/$ECR_REPOSITORY:$IMAGE_TAG

Troubleshooting

Common Issues

ECR Pull Errors

# Re-authenticate Docker
aws ecr get-login-password --region us-west-2 | docker login --username AWS --password-stdin ACCOUNT_ID.dkr.ecr.us-west-2.amazonaws.com

EKS Node Not Ready

# Check node status
kubectl describe node <node-name>

# Check node logs
kubectl logs -n kube-system -l k8s-app=aws-node

ECS Task Stuck in PENDING

# Check task events
aws ecs describe-tasks --cluster my-ecs-cluster --tasks <task-id> --region us-west-2

Navigation Menu

Repository navigation

setup_ECR-ECS-EKS.md

setup_ECR-ECS-EKS.md

AWS Container Services Setup Guide: ECR, ECS, and EKS

Table of Contents

1. Prerequisites

1.1. Required Tools

1.2. AWS Configuration

2. Amazon ECR Setup

2.1. Create ECR Repository (CLI)

2.2. Build and Push Docker Image

2.3. ECR IAM Policy

3. Amazon ECS Setup

3.1. Create ECS Cluster (CLI)

3.2. Create ECS Task Definition

3.3. Create ECS Service

3.4. Create Application Load Balancer

4. Amazon EKS Setup

4.1. Create EKS Cluster (eksctl)

4.2. Create Kubernetes Deployment for ECR Image

4.3. Create Image Pull Secret

5. Terraform IaC Examples

5.1. ECR Terraform Module

5.2. EKS Terraform Module

6. Security Best Practices

6.1. IAM Roles and Policies

6.2. Security Groups

6.3. Secrets Management

7. Monitoring and Logging

7.1. CloudWatch Logs

7.2. CloudWatch Metrics

7.3. X-Ray Tracing

8. CI/CD Integration

8.1. GitHub Actions Example

Troubleshooting

Common Issues

References

By Harshhaa Reddy

FilesExpand file tree

setup_ECR-ECS-EKS.md

Latest commit

History

setup_ECR-ECS-EKS.md

File metadata and controls

AWS Container Services Setup Guide: ECR, ECS, and EKS

Table of Contents

1. Prerequisites

1.1. Required Tools

1.2. AWS Configuration

2. Amazon ECR Setup

2.1. Create ECR Repository (CLI)

2.2. Build and Push Docker Image

2.3. ECR IAM Policy

3. Amazon ECS Setup

3.1. Create ECS Cluster (CLI)

3.2. Create ECS Task Definition

3.3. Create ECS Service

3.4. Create Application Load Balancer

4. Amazon EKS Setup

4.1. Create EKS Cluster (eksctl)

4.2. Create Kubernetes Deployment for ECR Image

4.3. Create Image Pull Secret

5. Terraform IaC Examples

5.1. ECR Terraform Module

5.2. EKS Terraform Module

6. Security Best Practices

6.1. IAM Roles and Policies

6.2. Security Groups

6.3. Secrets Management

7. Monitoring and Logging

7.1. CloudWatch Logs

7.2. CloudWatch Metrics

7.3. X-Ray Tracing

8. CI/CD Integration

8.1. GitHub Actions Example

Troubleshooting

Common Issues

References

By Harshhaa Reddy
